Radius Grates
Que Radius Grates
We took the ordinary vertical lines of a traditional slotted grate and turned them sideways, giving our Que pattern a long, lean look with eye-catching depth and dimension.
Select Size:
Detailed Specifications:
- Name / Design
- Que 12" Wide Heel-Proof, Heavy-Duty, 23'-9" CLR
- Product ID
- QUR12-19AM9924HPHD
- Dimensions
- 11.88" x 19.02" x 1.50"
- Fits
-
Iron Age Custom Frame
- Material
- Cast Aluminum
- Standard Finish
- Raw
- Optional Finishes
-
- Powder Coat
- Weight lb(s)
- 18.71
- Free Drain Area
- 14.93%
- Gallons Per Minute (GPM)
- 43.28
- Recycled Content
- 80%
- ADA Compliant
- Yes
- Optional Material Upgrades
-
- Cast Bronze
- Cast Ductile Iron
Photo Gallery:
Click image for high-res file and description
Que 5″ radius trench grate, raw nickel bronze, arrayed with various radii. DESIGN: Starr Whitehouse PROJECT: E92nd Street Bonus Plaza and Terraces. LOCATION: New York, NY.
Que 5″ radius trench grate, raw nickel bronze, arrayed with various radii. DESIGN: Starr Whitehouse PROJECT: E92nd Street Bonus Plaza and Terraces. LOCATION: New York, NY.
Que 5″ radius trench grate, raw nickel bronze, arrayed with various radii. DESIGN: Starr Whitehouse PROJECT: E92nd Street Bonus Plaza and Terraces. LOCATION: New York, NY.
Que 5″ radius trench grate, raw nickel bronze, arrayed with various radii. DESIGN: Starr Whitehouse PROJECT: E92nd Street Bonus Plaza and Terraces. LOCATION: New York, NY.
Que 5″ wide radius trench grates, cast iron with powder coat finish. DESIGN: NYC Parks. PROJECT: Playground 52, Kelly Street. LOCATION: Bronx, NY.
Que 10″ wide radius heel-proof trench grate, cast ductile iron with baked-on-oil finish. DESIGN: PWP Landscape Architecture. INSTALLER: Posillico. PROJECT: One Vanderbilt. LOCATION: New York, NY.
Que 10″ wide radius heel-proof trench grate, cast ductile iron with baked-on-oil finish. DESIGN: PWP Landscape Architecture. INSTALLER: Posillico. PROJECT: One Vanderbilt. LOCATION: New York, NY.
Que 10″ wide radius heel-proof trench grate, cast ductile iron with baked-on-oil finish. DESIGN: PWP Landscape Architecture. INSTALLER: Posillico. PROJECT: One Vanderbilt. LOCATION: New York, NY.
Que 10″ wide radius heel-proof trench grate, cast ductile iron with baked-on-oil finish. DESIGN: PWP Landscape Architecture. INSTALLER: Posillico. PROJECT: One Vanderbilt. LOCATION: New York, NY.
Que 10″ wide radius heel-proof trench grate, cast ductile iron with baked-on-oil finish. Shown three years after installation. DESIGN: PWP Landscape Architecture. INSTALLER: Posillico. PROJECT: One Vanderbilt. LOCATION: New York, NY.
Que 10″ wide radius heel-proof trench grate, cast ductile iron with baked-on-oil finish. Shown three years after installation. DESIGN: PWP Landscape Architecture. INSTALLER: Posillico. PROJECT: One Vanderbilt. LOCATION: New York, NY.
Que 10″ wide radius heel-proof trench grate, cast ductile iron with baked-on-oil finish. Shown three years after installation. DESIGN: PWP Landscape Architecture. INSTALLER: Posillico. PROJECT: One Vanderbilt. LOCATION: New York, NY.
Que 10″ wide radius heel-proof trench grate, cast ductile iron with baked-on-oil finish. Shown three years after installation. DESIGN: PWP Landscape Architecture. INSTALLER: Posillico. PROJECT: One Vanderbilt. LOCATION: New York, NY.
Que 12″ wide radius trench grate, cast ductile iron with e-coat plus black powder coat finish. DESIGN: TBG Partners. INSTALLATION: Rotolo Consultants (RCI). PROJECT: Our Lady of the Lake Children’s Hospital. LOCATION: Baton Rouge, LA.
Que 12″ wide radius trench grate, cast ductile iron with e-coat plus black powder coat finish. DESIGN: TBG Partners. INSTALLATION: Rotolo Consultants (RCI). PROJECT: Our Lady of the Lake Children’s Hospital. LOCATION: Baton Rouge, LA.
Que 12″ wide radius trench grate, cast ductile iron with e-coat plus black powder coat finish. DESIGN: TBG Partners. INSTALLATION: Rotolo Consultants (RCI). PROJECT: Our Lady of the Lake Children’s Hospital. LOCATION: Baton Rouge, LA.
Similar Products:
View additional products featuring the Que design
Standard Finish
For details, see Materials and Finish Options under Resources.
Optional Finish
For details, see Materials and Finish Options under Resources.
Optional Material Upgrades
Call for pricing and lead time.
